The 596PRA-2PV and 596PRA-3PV configurations build on the standard 596PRA by adding Poly-V belt drives that transmit power to adjacent rollers through lengthwise belt grooves. Poly-V results in increased torque transfer and higher per-zone capacities, with the 2-rib belt supporting up to about 110 lb per zone and the 3-rib belt supporting up to approximately 350 lb per zone at typical operating speeds.
Rollers remain set high in the 5-inch frame, and accumulation zones are actuated by photoeyes over 36-inch lengths. This variant is suited to applications where heavier loads or higher belt torque are required without increasing individual roller motor size.
Applications
- Carton and tote conveying
- Accumulation and buffering between processes
- Sortation and routing operations
- Order fulfillment and distribution
- Packaging and labeling lines
Industries
- Distribution and warehousing
- E-commerce and fulfillment
- Manufacturing and assembly
- Packaging operations
- Logistics and material handling
SPECIFICATIONS
| TREAD ROLLERS | 1.9 in. dia. x 16 ga. galvanized, model 196G with Poly-V belt drive adapter |
| DRIVE BELT | 596PRA-2PV: 2 rib Poly-V belt; 596PRA-3PV: 3 rib Poly-V belt |
| CAPACITY | 2 rib Poly-V belt: 110 lbs per zone at 60 FPM (maximum capacity). 3 rib Poly-V belt: 350 lbs per zone at 53 FPM (maximum capacity) |
| ROLLER CENTERS | 3 in. or 4 in. |
| BED / FRAME | 5 in. x 1-3/4 in. x 10 ga. formed steel channel frame, rollers set high in frame |
| SPEED | 60 FPM constant |
| ACCUMULATION | Zone singulation operation, 36 in. zone length, photoeye actuated |
| MOTOR DRIVE | Driven by 24V DC Powered Roller |
| BEARINGS | Precision ABEC bearings |
| DC POWER SUPPLY | 24 volt fixed output required |
DETAILS
ACCESORIES / OPTIONS
Zone Lengths
Floor Supports
Ceiling Hangers
Speed
Motors
Defused Smart Zone®
WARRANTY
Electrical: 12 Months
Mechanical: 12 Months
