The 796LSX cross-over module facilitates the routing of products over an adjacent conveyor path, maintaining continuity of movement without interfering with drive shaft alignment. Available with left or right cross-over orientations, this component simplifies complex system layouts.
Cross-over modules are often used where conveyors need to intersect or bypass other equipment, enabling efficient spatial use in compact facilities.
Applications
- Carton accumulation and release zones
- Order fulfillment conveyor lines
- Sortation in low to moderate speed systems
- Packaging and operations
- Transfer between processing stations
Industries
- Distribution and fulfillment
- E-commerce operations
- Light manufacturing
- Packaging and assembly
- Third-party logistics
SPECIFICATIONS
| BF | 15", 19", 21", 25", 27", 33", 39" |
| OAW | 18", 22", 24", 28", 30", 36", 42" |
| TREAD ROLLERS | 1.9" dia. x 16 ga. galvanized, model 196G grooved |
| DRIVE BELT | 3/16" dia. polyurethane belts; nominal 15 lbs. per roller drive |
| DRIVE SHAFT | 1" dia. C1018 cold rolled steel shaft |
| BED / FRAME | 7" x 1-1/2" x 12 ga. formed steel channel frame |
| CROSS OVER DIRECTION | Specify "cross over to right hand" or "cross over to left hand" |
| COUPLINGS | Located on both, one, or no end |
| MOTOR DRIVE | 1/2 HP, 230/460/3, 60 cycle, Super "E" right angle gear motor |
| SPEED | 60 FPM. |
| FLOOR SUPPORTS | Optional |
DETAILS
ACCESORIES / OPTIONS
Side Mounted Drive
Floor Supports
Speed
Motors
Controls
WARRANTY
Electrical: 12 Months
Mechanical: 12 Months
